Allied Telesis Enterprise-class TQ3403 wireless access point features Wi-Fi 6E technology for high performance. A Multi-Gigabit uplink port removes upstream bottlenecks for a superior wireless solution.
Key Features
Specifications
Physical
| Product | Width x Depth x Height | Weight | 100M/1G/2.5G (RJ-45) Copper Ports | |
|---|---|---|---|---|
| TQ3403 | 200 x 210 x 47 mm (7.87 x 8.23 x 1.85 in) |
2 x 2 (2.4GHz) + 2 x 2 (5GHz) + 2 x 2 (6GHz) |
1.1 kg (2.43 lb) | 1 (PoE-in port) |
Power Characteristics
| Product | Power Supply | Average Power Consumption | Maximum Power Consumption | Max Heat Dissipation |
|---|---|---|---|---|
| TQ3403 | 100-240VAC | 15W | 20W | 61.4 BTU/h |
| PoE | 14W | 24W | 66.15 BTU/h |
Ordering Information
AT-TQ3403-xx
Enterprise-Class Wi-Fi 6 AP with 3 radios
(2×2 2.4GHZ, 2×2 5GHz, and 2×2 6GHz) and embedded antenna
Where xx =
05 Other countries(1)
02 Taiwan
(1) Please check the Compliance section on page 2 of the datasheet to see which countries are certified to use this access point
AT-PWRADP-01
AC adapter
AT-6101GP-yy
Gigabit Ethernet PoE+ (802.3at) injector
AT-7101GHTm-yy
Multi-Gigabit Ethernet PoE++ (802.3bt) injector
AT-BRKT-CONV-AP1
Replacement bracket converter
Where yy =
10 for US power cord
30 for UK power cord
40 for Australian power cord
50 for European power cord
Wireless Management Licenses
Wireless management of the TQ3403 is from the Vista Manager EX network management platform, and from Vista Manager mini(3) running on the switch and firewall products listed in the following table.
| Platform | License Name | Description | Max Supported APs |
|---|---|---|---|
| Vista Manager EX | AT-FL-VISTA-BASE-1/5YR | Vista Manager EX network monitoring and management software license | NA |
| Vista Manager EX (Windows) | AT-FL-VISTA-AWC10-1/5YR(4) | Vista Manager AWC plug-in license for managing up to 10 access points | 3000 |
| Vista Manager EX (Virtual (VRT)) | AT-FL-VISTA-AWC10-1/5YR(4) | Vista Manager AWC plug-in license for managing up to 10 access points | 500 |
| Vista Manager EX (Network Appliance) | AT-FL-VISTA-AWC10-1/5YR(4) | Vista Manager AWC plug-in license for managing up to 10 access points | 500 |
| SwitchBlade x908 GEN2 | AT-SW-AWC10-1/5YR(5) | Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points | 305 |
| x950 Series | AT-SW-AWC10-1/5YR(5) | Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points | 185 |
| x930 Series | AT-SW-AWC10-1/5YR(5) | Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points | 125 |
| x550 Series | AT-SW-AWC10-1/5YR(5) | Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points | 45 |
| x540L Series | AT-SW-AWC10-1/5YR(5) | Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points | 45 |
| x530 Series | AT-SW-AWC10-1/5YR(5) | Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points | 45 |
| ARX200S-GTX | AT-RT-AWC10-1/5YR(6) | Cumulative Autonomous Wave Controller (AWC) license for up to 10 access points | 30 |
| AR4050S UTM Firewall | AT-RT-AWC5-1/5YR(5) | Cumulative Autonomous Wave Controller (AWC) license for up to 5 access points | 25 |
(3) Wireless management from Vista Manager mini will be available in a future firmware release
(4) The AWC plug-in requires an AWC license, and a Vista Manager EX base license to operate on Vista Manager EX
(5) 5 APs can be managed for free. Purchase one license per 10 additional APs on switches, or one license per 5 additional APs on the AR4050S Firewall
(6) 20 APs can be managed for free on the ARX200S-GTX, and an additional 10 APs with a license
