Powerful firewall security and threat protection is combined with routing and switching to provide an innovative high-performance solution. The 5G model enables flexible WAN deployment for your distributed business using high-speed 5G mobile broadband to link remote offices to the corporate network, or to back up a wired Internet connection.
Ensure secure access to business applications from anywhere across the corporate WAN.
| AR3050S | AR4050S | AR4050S-5G | |
|---|---|---|---|
| Security processor | 800MHz dual-core | 1.5GHz quad-core | |
| Memory (RAM) | 1GB | 2GB | |
| Memory (Flash) | 4GB | 4GB | |
| Max power consumption | 23W | 27W | 28W |
| 5G mobile connectivity | – | – | 2 x SIM card slots |
| High Availability bypass ports | 2 x 10/100/1000T RJ-45 | – | |
| LAN ports | 8 x 10/100/1000T RJ-45 | ||
| WAN ports | 2 x 1000X SFP / 2 x 10/100/1000T RJ-45 combo | 2 x 10/100/1000T RJ-45 | |
| Other ports | 1 x USB, 1 x RJ-45 console, 1 x SDHC slot | 1 x USB, 1 x RJ-45 console | |
| AR3050S | AR4050S / AR4050-5G | |
|---|---|---|
| Firewall throughput (Raw) | 750 Mbps | 1,900 Mbps |
| Firewall throughput (App Control) | 700 Mbps | 1,800 Mbps |
| Concurrent sessions | 100,000 | 300,000 |
| New sessions per second | 3,600 | 12,000 |
| IPS throughput | 220 Mbps | 750 Mbps |
| IP Reputation throughput | 350 Mbps | 1,000 Mbps |
| Malware protection throughput | 300 Mbps | 1,300 Mbps |
| VPN throughput | 400 Mbps | 1,000 Mbps |
Note: All performance values are maximums, and vary depending on system configuration.
2 x GE WAN and 8 x 10/100/1000 LAN
2 x GE WAN and 8 x 10/100/1000 LAN
2x 10/100/1000 WAN and 8x 10/100/1000 LAN
with 5G(1) mobile broadband access and dual SIM slots
(1) 5G connectivity is not supported in Vietnam, but the AR4050S-5G can still be used at 3G or 4G speeds
Rack mount kit to install two devices side by side in a
19-inch equipment rack
Rack mount kit to install one device in a 19-inch
equipment rack
Stand-kit
| License Name | Includes | 1 year Subscription | 3 year Subscription | 5 year Subscription |
|---|---|---|---|---|
| Advanced Firewall | Application Control Web Control |
AT-AR3-UTM-01-1YR | AT-AR3-UTM-01-3YR | AT-AR3-UTM-01-5YR |
| License Name | Includes | 1 year Subscription | 3 year Subscription | 5 year Subscription |
|---|---|---|---|---|
| Advanced Firewall | Application Control Web Control |
AT-AR4-UTM-01-1YR(1) | AT-AR4-UTM-01-3YR(1) | AT-AR4-UTM-01-5YR(1) |
| Advanced Threat Protection | Advanced IPS IP Reputation |
AT-AR4-UTM-02-1YR(1) | AT-AR4-UTM-02-3YR(1) | AT-AR4-UTM-02-5YR(1) |
(1) The AT-AR4-UTM-01 and AT-AR4-UTM-02 licenses cannot be used together
| Name | Description | Includes |
|---|---|---|
| AT-FL-UTM-OFFLOAD-1YR | UTM Offload license for 1 year | UTM Offload license for 1 year |
| AT-FL-UTM-OFFLOAD-3YR | UTM Offload license for 1 year | UTM Offload license for 3 years |
| AT-FL-UTM-OFFLOAD-5YR | UTM Offload license for 1 year | UTM Offload license for 5 years |
| AT-RT-APM5-1YR(2),(3) | Cumulative AMF Plus Master license | AMF Plus Master license for up to 5 nodes for 1 year |
| AT-RT-APM5-5YR(2),(3) | Cumulative AMF Plus Master license | AMF Plus Master license for up to 5 nodes for 5 years |
| AT-RT-AWC5-1YR(4) | Cumulative AWC license | Autonomous Wave Control (AWC) license for up to 5 access points for 1 year |
| AT-RT-AWC5-5YR(4) | Cumulative AWC license | Autonomous Wave Control (AWC) license for up to 5 access points for 5 years |
| AT-RT-CB5-1YR-2022(5) | AWC-CB and AWC-SC license | AWC Channel Blanket and AWC Smart Connect license for up to 5 access points for 1 year |
| AT-RT-CB5-5YR-2022(5) | AWC-CB and AWC-SC license | AWC Channel Blanket and AWC Smart Connect license for up to 5 access points for 5 years |
| AT-FL-AR4-ASEC-1YR(6) | AMF-Sec license | AMF-Sec license for 1 year |
| AT-FL-AR4-ASEC-5YR(6) | AMF-Sec license | AMF-Sec license for 5 years |
(2) From AW+ version 5.5.2-2 onwards, AMF Plus licenses provide all standard AMF network management and automation features. They also enable the AMF Plus intent-based networking features menu in Vista Manager EX (from version 3.10.1 onwards)
(3) Purchase one license per 5 nodes (up to 20 nodes maximum)
(4) 5 APs can be managed for free. Purchase one license per 5 additional APs (up to 25 APs maximum)
(5) Channel Blanket and Smart Connect are not available as free services. Both an AWC-CB license and an AWC license are required for Channel Blanket and/or Smart Connect to operate. (Channel Blanket is supported on TQ6602, TQ5403, and TQ5403e access points. Smart Connect is supported on TQ5403, and TQ5403e access points)
(6) To use AMF-Sec in conjunction with either the Advanced Firewall (NGFW) or Advanced Threat Protection (ATP) licenses, you must have AMF-Sec mini version 2.2.1 or newer
