A cost-effective way for small businesses to integrate management and Gigabit Ethernet at the edge of network.
Overview
Key Features
Specifications
| Product | 10/100/1000T Copper Ports | 1000X SFP Ports | Total Ports | PoE Enabled Ports | Switching Fabric | Forwarding Rate |
|---|---|---|---|---|---|---|
| GS950/8 | 6 + 2 (Combo) | 2 (Combo) | 8 | – | 16Gbps | 11.90Mpps |
| GS950/8POE | 6 + 2 (Combo) | 2 (Combo) | 8 | 4(1) | 16Gbps | 11.90Mpps |
| GS950/10PS | 8 + 2 (Combo) | 2 (Combo) | 10 | 8 | 20Gbps | 14.88Mpps |
| GS950/16 | 14 + 2 (Combo) | 2 (Combo) | 16 | – | 32Gbps | 23.80Mpps |
| GS950/16PS | 14 + 2 (Combo) | 2 (Combo) | 16 | 16 | 32Gbps | 23.80Mpps |
| GS950/24 | 20 + 4 (Combo) | 4 (Combo) | 24 | – | 48Gbps | 35.71Mpps |
| GS950/28PS | 24 | 4 | 28 | 24 | 56Gbps | 41.66Mpps |
| GS950/48 | 44 + 4 (Combo) | 4 (Combo) | 48 | – | 96Gbps | 71.42Mpps |
| GS950/48PS | 44 + 4 (Combo) | 4 (Combo) | 48 | 24 | 96Gbps | 71.42Mpps |
(1) Only POE (15.4W) can be supported
Physical
| Product | Width | Depth | Height | Weight |
|---|---|---|---|---|
| GS950/8 | 280 mm (11.02 in) | 180 mm (7.09 in) | 44 mm (1.73 in) | 1.50 Kg (3.30 lbs) |
| GS950/8POE | 330 mm (13.00 in) | 230 mm (9.06 in) | 43 mm (1.70 in) | 2.54 Kg (5.60 lbs) |
| GS950/10PS | 330 mm (13.00 in) | 200 mm (7.90 in) | 44 mm (1.73 in) | 1.90 Kg (4.20 lbs) |
| GS950/16 | 330 mm (13.00 in) | 200 mm (7.90 in) | 44 mm (1.73 in) | 2.10 Kg (4.60 lbs) |
| GS950/16PS | 430 mm (17.00 in) | 250 mm (9.80 in) | 44 mm (1.73 in) | 3.56 Kg (7.85 lbs) |
| GS950/24 | 330 mm (13.00 in) | 200 mm (7.90 in) | 44 mm (1.73 in) | 2.30 Kg (5.10 lbs) |
| GS950/28PS | 450 mm (17.71 in) | 250 mm (9.80 in) | 44 mm (1.73 in) | 3.60 Kg (7.93 lbs) |
| GS950/48 | 444 mm (17.48 in) | 257 mm (10.12 in) | 43.2 mm (1.70 in) | 4.10 Kg (9.00 lbs) |
| GS950/48PS | 440 mm (17.32 in) | 430 mm (17.00 in) | 44 mm (1.73 in) | 6.62 Kg (14.60 lbs) |
Power and Noise Characteristics
| Product | No PoE Load Max Power Consumption (W) | No PoE Load Max Heat Dissipation (BTU/h) | No PoE Load Noise (dBA) | Full PoE+ Load Max Power Consumption (W) | Full PoE+ Load Max Heat Dissipation (BTU/h) | Full PoE+ Load Noise (dBA) |
|---|---|---|---|---|---|---|
| GS950/8 | 8.7 | 29.69 | Fanless | – | – | – |
| GS950/8POE | 10 | 34.12 | Fanless | 87.5 | 298.56 | Fanless |
| GS950/10PS | 14.44 | 49.27 | Fanless | 92.7 | 316.31 | Fanless |
| GS950/16 | 12.92 | 44.08 | Fanless | – | – | – |
| GS950/16PS | 21.8 | 74.38 | 47 dB@98% >25C 38.2dB@52% <25C |
228.5 | 779.67 | 47 dB@98% >25C 38.2dB@52% <25C |
| GS950/24 | 17.35 | 59.20 | Fanless | – | – | – |
| GS950/28PS | 28.6 | 97.59 | 58.5dB >25C 55.2dB <25C |
238 | 812.09 | 58.5dB >25C 55.2dB <25C |
| GS950/48 | 42.97 | 146.62 | 47 dB@98% >25C 38.2dB@52% <25C |
– | – | – |
| GS950/48PS | 55.6 | 189.72 | 51.6dB >25C 38.7dB <25C |
446 | 1,521.82 | 51.6dB >25C 38.7dB <25C |
Note: Noise values are dependent on the ambient temperature, not POE load. Above 25C the fan runs at full speed
Power over Ethernet
| Product | PoE Budget Power (W) | 7.5W PoE Sourcing Ports | 15.4W PoE Sourcing Ports | 30W PoE+ PoE Sourcing Ports |
|---|---|---|---|---|
| GS950/8 | – | – | – | – |
| GS950/8POE | 61.6 | 4 | 4 | – |
| GS950/10PS | 75 | 8 | 4 | 2 |
| GS950/16 | – | – | – | – |
| GS950/16PS | 185 | 16 | 12 | 6 |
| GS950/24 | – | – | – | – |
| GS950/28PS | 185 | 24 | 12 | 4(2) |
| GS950/48 | – | – | – | – |
| GS950/48PS | 370 | 24 | 24 | 12 |
(2) It supports between port-1 and port-4 (Only 4 ports can be used with 30W PoE power budget)
Ordering Information
Model availability can vary between regions. Please check our website to see which models are available in your region.
AT-GS950/8-xx(1)
8-port 10/100/1000T eco-friendly WebSmart
switch with 2 SFP combo ports
AT-GS950/16-xx(1)
16-port 10/100/1000T eco-friendly WebSmart
switch with 2 SFP combo ports
AT-GS950/24-xx(1)
24-port 10/100/1000T eco-friendly WebSmart
switch with 4 SFP combo ports
AT-GS950/48-xx(1)
48-port 10/100/1000T eco-friendly WebSmart
4 SFP+ ports and 2 fixed DC power supplies
AT-GS950/8POE-xx
8 port 10/100/1000T PoE fanless WebSmart
switch with 2 SFP combo ports
AT-GS950/10PS-xx
10-port 10/100/1000T POE+ (8 POE+ Enabled)
WebSmart switch with 2 SFP combo ports
AT-GS950/16PS-xx
16-port 10/100/1000T POE+ WebSmart switch
with 2 SFP combo ports
AT-GS950/28PS-xx
24-port 10/100/1000T POE+ WebSmart switch
with 4 SFP ports
AT-GS950/48PS-xx
48-port 10/100/1000T POE+ (24 POE+ Enabled)
WebSmart switch with 4 SFP combo ports
(1) Trade Act Agreement compliant
Where xx =
10 for US power cord
20 for no power cord
30 for UK power cord
40 for Australian power cord
50 for European power cord
All Models
