Flexible Power over Ethernet switches with capabilities that support IoT device connectivity in today’s converged business environments.
Overview
Key Features
Specifications
| Product | 10/100/1000T (RJ-45) PoE Enabled Ports | 10/100/1000T (RJ-45) PoE-in Port | 1000X SFP Ports | Switching Fabric | Forwarding Rate |
|---|---|---|---|---|---|
| GS980EM/10H | 8 | – | 2 | 24Gbps | 14.9Mpps |
| GS980EM/11PT | 8 | 1 | 2 | 24Gbps | 16.4Mpps |
Physical
| Product | Width x Depth x Height | Mounting | Unpackaged Weight | Packaged Weight | Packaged Dimensions |
|---|---|---|---|---|---|
| GS980EM/10H | 210 x 180 x 42.5 mm (8.26 x 7.08 x 1.67 in) |
Rack-mount | 1.6 kg (3.53 lb) | 2.7 kg (5.95 lb) | 417 x 336 x 151 mm (16.42 x 13.23 x 1.67 in) |
| GS980EM/11PT | 210 x 180 x 42.5 mm (8.26 x 7.08 x 1.67 in) |
Rack-mount | 1.6 kg (3.53 lb) | 3.5 kg (7.71 lb) | 417 x 336 x 151 mm (16.42 x 13.23 x 1.67 in) |
Power Characteristics
| Product | Maximum PoE Power | 7.5W Max PoE Ports Supported | 15.4W Max PoE Ports Supported | 30W PoE+ Max PoE Ports Supported | 60W PoE++ Max PoE Ports Supported | 90W PoE++ Max PoE Ports Supported | Max No PoE Load Power Consumption (W) | Max No PoE Load Heat Dissipation (BTU/h) | Full PoE Load Max Power Consumption (W) | Full PoE Load Max Heat Dissipation (BTU/h) |
|---|---|---|---|---|---|---|---|---|---|---|
| x320-10GH | 240W (PWR300 x 1) | 8 | 8 | 8 | 4 | 2 | 21 | 71 | 320 | 218 |
| 480W (PWR300 x 2) | 8 | 8 | 8 | 8 | 5 | 21 | 71 | 600 | 409 | |
| 720W (PWR300 x 3) | 8 | 8 | 8 | 8 | 8 | 21 | 71 | 880 | 600 | |
| GS980EM/11PT | 0W (switch powered by 30W PoE) (1) | 0 | 0 | 0 | 0 | 0 | 22 | 75 | 98 (using AC power adapter) | 350 (using AC power adapter) |
| 31.6W (switch powered by 60W PoE) (1) | 4 | 2 | 1 | 0 | 0 | 22 | 75 | 98 (using AC power adapter) | 350 (using AC power adapter) | |
| 46.2W (switch powered by 90W PoE) (1) | 6 | 3 | 1 | 0 | 0 | 22 | 75 | 98 (using AC power adapter) | 350 (using AC power adapter) | |
| 62W (switch powered by AC Adaptor) | 8 | 4 | 2 | 0 | 0 | 22 | 75 | 98 (using AC power adapter) | 350 (using AC power adapter) |
(1) The GS980EM/11PT uses PD port 11 to receive PoE power, but cannot be powered by PoE if the AC adapter is connected
Ordering Information
AT-GS980EM/10H
8-port 10/100/1000T PoE++ switch with 2 SFP
ports, and 3 external PSU ports(2)
AT-GS980EM/11PT
8-port 10/100/1000T PoE+ switch with 2 SFP
ports, one AC adapter port(3) , and one PoE-in port(4)
(supporting PD and PoE pass-through)
Power Supplies
AT-PWR300-xx
300W PoE power supply (for GS980EM/10H and
x320-10GH switches)
Where xx =
10 for US power cord
20 for no power cord
30 for UK power cord
40 for Australian power cord
50 for European power cord
19 inch rack-mount brackets included with every switch
(2) PWR300 power supplies for the GS980EM/10H must be ordered separately
(3) The GS980EM/11PT ships with an AC power adapter
(4) The GS980EM/11PT can be powered by PoE from 30W (class 4) to 90W (class 8)
Feature Licenses
| Name | Description | Includes |
|---|---|---|
| AT-FL-G98EM-01 | GS980EM Premium license | OSPF (128 routes) PIMv4-SM, DM and SSM RIPng (256 routes) STATIC (128 Routes) EPSR Master |
