The IE360 Series Industrial Ethernet Layer 3 switches provide secure data transfer to support critical infrastructure in harsh environments, such as industrial automation, marine, oil and gas, transportation, and more. The Power over Ethernet (PoE++) model enables connecting and powering key endpoints and IoT devices for seamless and efficient infrastructure operation.
| Product | 10/100/1000T (RJ-45) Copper Ports | 100/1000X SFP Ports | 1/10G SFP+ Ports | Total Ports | PoE Enabled Ports | Switching Fabric | Forwarding Rate |
|---|---|---|---|---|---|---|---|
| IE360-12GHX | 8 | 2 | 2 w/ MACsec | 12 | 8 | 60Gbps | 44.6Mpps |
| IE360-12GTX | 8 | 2 | 2 w/ MACsec | 12 | – | 60Gbps | 44.6Mpps |
| Product | Width x Depth x Height | Weight | Enclosure | Mounting | Protection Rate |
|---|---|---|---|---|---|
| IE360-12GHX | 91 x 158 x 153 mm (3.58 x 6.23 x 6.02 in) |
DIN rail: 2.2 kg (4.88 lbs) Wall mount: 2.1 kg (4.64 lbs) |
Aluminium/Stainless Steel Sheet Metal shell |
DIN rail, wall mount | IP30 |
| IE360-12GTX | 91 x 158 x 153 mm (3.58 x 6.23 x 6.02 in) |
DIN rail: 2.1 kg (4.64 lbs) Wall mount: 2.06 kg (4.54 lbs) |
Aluminium/Stainless Steel Sheet Metal shell |
DIN rail, wall mount | IP30 |
| Product | Input Voltage | Cooling | No PoE Load Max Power Consumption | No PoE Load Max Heat Dissipation | No PoE Load Noise | Full PoE Load(1) Max Power Consumption | Full PoE Load(1) Max Heat Dissipation | Full PoE Load(1) Noise |
|---|---|---|---|---|---|---|---|---|
| IE360-12GHX | 18~57V DC(2) | Fanless | 29.9W | 102.0 BTU/hr | – | 406.5W | 158.7 BTU/hr | – |
| IE360-12GTX | 18~57V DC | Fanless | 25.0W | 85.3 BTU/hr | – | – | – | – |
(1) The Max Power consumption at full PoE load includes the powered device’s consumption and margin. The cooling requirements of the switch are smaller than the power draw, because most of the load is dissipated at the PoE powered device and along the cabling. Use these wattage and BTU ratings for facility capacity planning.
(2) Note: PoE sourcing requires the input voltage ≥ 36V DC
| Product | Enabled PoE Ports PoE | Max PoE Power Budget(3) | Max PoE Sourcing Ports PoE (15W) | Max PoE Sourcing Ports PoE+ (30W) | Max PoE Sourcing Ports PoE++ (60W) | Max PoE Sourcing Ports PoE++ (95W) |
|---|---|---|---|---|---|---|
| IE360-12GHX | 8 | 360W | 8 | 8 | 6 | 3 |
| IE360-12GTX | – | – | – | – | – | – |
(3) The PoE power budget is shared among all ports; we recommend configuring dynamic PoE power allocation to optimize the power distribution.
| Product | 100Mbps Port Speed | 1Gbps Port Speed | 10Gbps Port Speed |
|---|---|---|---|
| IE360-12GHX | 10.98µs | 2.44µs | 1.62µs |
| IE360-12GTX | 11.02µs | 2.22µs | 1.62µs |
The DIN rail and wall mount kits are included.
The management serial console cable is NOT included.
8x 10/100/1000T, 2x 100/1000X SFP
2x 1G/10G SFP+
Industrial Ethernet, Layer 3 Switch
PoE++ Support
8x 10/100/1000T, 2x 100/1000X SFP
2x 1G/10G SFP+
Industrial Ethernet, Layer 3 Switch
(1) Trade Act Agreement compliant
120W @48Vdc, Industrial AC/DC power supply,
DIN rail mount (5 years warranty)
240W @48Vdc, Industrial AC/DC power supply,
DIN rail mount (5 years warranty)
480W @48Vdc, Industrial AC/DC power supply,
DIN rail mount (5 years warranty)
120W @48Vdc, Industrial AC/DC power supply,
DIN rail mount
240W @48Vdc, Industrial AC/DC power supply,
DIN rail mount
480W @48Vdc, Industrial AC/DC power supply,
DIN rail mount
| Name | Description | Includes |
|---|---|---|
| AT-IE360-FL01 | IE360 Series Premium license | BGP, BGP+ (256 routes) OSPF (256 routes) OSPFv3 (256 routes) PIM-SM, DM and SSM (256 routes) PIMv6-SM and SSM (256 routes) RIP (256 routes) RIPng (256 routes) |
